A solid mud-ready workhorse. Built purely for off-road riding. Perfect for farm use and off-road adventure.
OFF-ROAD Only
50kph | 30mph Top speed
150lb/68kg Weight incl. power supply
120km / 75mi Max range
3.1kWH Battery
4-6 hours Charge time (Includes Fast Charger)
Off-road Range: 80km / 50mi
Max Payload (including rider): 150kg / 330lbs
Designed tough and built for hard work and adventure. With all-wheel drive traction the 2X2 Work Bike can handle the hills, the mud, and the daily grind without disturbing the sounds of nature.
All-wheel drive: All-wheel drive is provided by a high-torque 1kW motor in each wheel for great acceleration and control in slippery or rough conditions. Fully sealed, the motors are designed to handle all off-road conditions.
Max speed:At 30mph/50kph you’ll have no trouble tackling tough trails or keeping the herd in the right direction. Change from eco to boost mode for some extra oomph.
Off road range: With around 50 miles (80 km) in off road conditions you can run all your essential errands or head out into the wild. Range is affected by variables such as weight, incline, and terrain. *75mi/120km achieved under test conditions.
To attach gear:Built to carry your tools and equipment, the bike has 19 lugs for attaching tie downs, mounts, and accessories. Strap on the chainsaw, bring your supplies, your lunch – even your dog.
Our two electric motors are located in the hub of each wheel. This means no chains, less noise, and no heat. The brushless DC motors are designed to handle tough off-road conditions with air cooling, sealed bearings, and fully splined gear interfaces.
The 3D alloy frame includes 19 conveniently located accessory lugs so you can strap on your tools and equipment. The lugs use standard M8 nuts and bolts for attaching tie downs, mounts and accessories. Carry all you need for whatever the job or adventure.
Our step through alloy frame is super lightweight and durable. Traverse rough terrain and around or over obstacles with ease and low injury risk. For easy transport on the back of your truck or car remove the battery and the frame is only 112lb/50kg.
Carry your tools, your equipment, or your toys without breaking a sweat. Whether you're working hard on the land, exploring deep into the forest, or logging miles of adventure, the UBCO 2X2 gets you places other vehicles can't.
If you know how to ride a bicycle then you can ride an UBCO. Our twist-and-go throttle means you go from standstill to 30mph/50kph with a twist of the wrist. Electric motors in each wheel means no gears, no clutch and responsive acceleration
With no exhaust, heat, sparks, or chains, the electric-drivee 2X2 eliminates many of the safety concerns of internal combustion motorcycles by design. Light, stable, and strong, the 2X2 Work Bike gives you complete control in all terrain.
Adjustable suspension: To improve handling and stability of the bike, the front and rear suspension is adjustable. This allows the rider to set the load ride height of the bike for various cases and terrains.
No gas. No emissions. No noise:Near silent motors let you enjoy the sounds around you without adding any noise pollution of your own. Exchanging a quad bike for an UBCO 2X2 will reduce carbon emissions by 99%, and fuel costs by 98%.
WORK BIKE DIMENSIONS
Weight excl battery: 50.7kg | 111.6lb
+ 3.1kWh battery: 68.7kg | 151.2lb
Height: 1,025mm | 40.4"
Seat height: 815mm | 32"
Width (handlebars): 820mm | 32.3"
Length: 1,820mm | 6'
Wheelbase: 1,215mm | 3.98'
All wheel drive.
2 x 1kw motors.
Brushless DC air cooled.
High durability planetary geared system.
Fully splined gear interfaces.
Sealed bearings.
Note: 3.1kWh Work Bike now comes with Dash
COST TO FILL (USD)
US$0.54 (0-100% 3.1kWh battery)
*based on average residential electricity $0.17/kWh
CO2 EMISSIONS
None
OPERATING VOLUME
Stationary: 0db | Full speed: 75db
REGENERATIVE BRAKING SYSTEM
Hydraulic & regenerative brakes operate together.
Active regenerative braking (brake activated) with independent front and rear brake control.
Passive regenerative braking (off throttle).
SR Brake System
2 Piston radial calipers
200mm rotors.
Sintered brake pads.
457mm2 pad surface area.
TOUGH WHEELS
9 gauge stainless steel spokes.
Tangential double-crossed lacing pattern.
17x1.85" aluminium rims (DOT compliant).
17x2.75" off-road tires.
SUPER X STRUCTURE
Step through alloy frame.
Front and rear racks standard.
19 drop forged attachment lugs on sub frame & rack.
Dual kickstands (stand bike on either side).
ADJUSTABLE SUSPENSION
Tapered chromoly steerer, chrome steel stanchions, alloy lower (corrosion resistant).
Coil spring with hydraulic dampener.
Preload & rebound adjustment.
120mm rear suspension.
Coil over spring with hydraulic dampener.
Preload & rebound adjustment.
HIGH CAPACITY BATTERY
Capacity options: 2.1kWh or 3.1kWh.
Dual safety system with active and passive safety.
Active Safety:
UBCO battery management system.
Real time performance and safety monitoring.
Passive Safety:
IP66 rated sealed alloy enclosure.
Vented enclosure with venting pathways.
3400 mAh high safety factor INR (LiNiMnCoO2) 18650 lithium ion cells.
Designed for disassembly at end of life.
FAST CHARGING
10amp alloy fast charger.
Rugged alloy casing.
Can be wall mounted.
Charger detect disables 2X2 when charging.
USER FRIENDLY CONTROLS
Fully electronic throttle control.
Handlebar mounted momentary switch control for horn.
Includes LCD dashboard with speed, battery charge, power levels, motor temperature and more.
LED LIGHTING
Powerful 2400 lumen floodlight headlight.
Compact and lightweight.
Environmentally sealed.
LED rear brake lights.
INTELLIGENT COMMUNICATION
Proprietary vehicle management system.
Integrates all electronic and electrical functions of the vehicle.
Provides control and updates with Bluetooth 5.0.
Vented waterproof enclosure with sealed automotive connectors.
Isolated CAN bus for easier integration of future CAN devices.
CAN communication with power supply.
BUILT IN SECURITY
Steering lock.
Battery locks to frame.
Keyless fob operation utilizes code hopping technology, hard to clone or hot-wire.
HANDY FIELD KIT
Fastens under the lift-up seat.
Contains user manual and tools to set up the 2X2.
VEHICLE CLASS
WMC PIN coded off road vehicle.
NOT road registrable:
CE Compliant for off-road use in Europe. Can be registered as a farm/work vehicle in some European jurisdictions.
RVCS approved for off-road use in Australia. Can be approved for a conditional registration for farm use.
Compliant for off-road use in NZ.
LICENSE REQUIREMENTS
Note: Check your local licensing laws to determine license requirements.
